Connectors basic 32A IP44 7P
Connectors basic 32A IP44 7P Connectors basic 7-poles 32A 6h.
| Type designation | S 732-6S |
|---|---|
| Rated current [A] | 32 |
| No.of Poles [pcs] | 7P |
| Rated voltage [V AC] | 400 |
| Frequency [Hz] | 50/60 |
| Degree of protection [IP] | 44 |
| Colour | Red |
| Standard | Class 1 EN 60044-8 |
| Width [mm] | 99 |
| Height [mm] | 168 |
| Depth [mm] | 99 |
| Netweight [kg] | 0.31 |
| Materials | Plastic |
| Function | Basic |
| Position of earth [h] | 6 |
| RAL-nummer | RAL3000 |
| Name | CONNECTORS 7P 32A 6h |
|---|---|
| E-number | 2425923 |
| Article number | 107762 |
